-70%FRSV1-180 - Vinyl Insulated Female Bullet Connectors - 22-16 AWG—
$8.12
$2.44The Story
Tin plated brass bullet type insulated terminals with copper sleeve on terminal barrel. Male and female fit to form a fully insulated in-line splice. This helps prevent shorting or flash-over when disconnected with power on.
Product Drawing:
None:
| Wire Range: | 22-16 AWG |
| W: | 0.01" (4.4mm) |
| F: | 0.33" (8.5mm) |
| L: | 0.84" (21.4mm) |
| B: | 0.40" (10.2mm) |
| D: | 0.15" (4.0mm) |
| C: | 0.06" (1.7mm) |
| Terminal Material: | Brass |
| Insulation Material: | Vinyl |
| Insulation Color: | Red |
| Temperature Rating: | 105oC - 600 Volts |
| Max AMP Rating: | 10 AMP |
| UL Recgonized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Product Drawing:
Cross References
Cross Reference Parts:None:
Documents
Click to view product spec sheet:Videos
